F612 船舶救生艇防坠落装置/CCS/LR/FPD/Fall Preventer Device For Lifeboat Equipmen
F612 FPD/Fall Preventer Device For Lifeboat Equipment/CCS/LR/SOLAS MSC. 1/ CIRC. 132
船舶救生艇防坠落装置/CCS/LR/
符合SOLAS MSC.1/CIRC.1327船级社协会IACS UI SC254的要求 吊索和卸扣双船检 德国橙色荧光防腐涂层 橙色护套+安全销 全球通用 1套（5/6T吊索2根+卸扣2只+不锈钢存放箱+双船检）
MSC：
On each ship, fall preventer devices in accordance with Guidelines for the fitting and use of fall preventer devices (FPDs) (MSC.1/Circ.1327) should be employed for each existing lifeboat release and retrieval system until the system is :
.1 found compliant with the LSA Code; or
.2 modified and found compliant with the LSA Code; or
.3 found compliant with paragraphs 4.4.7.6.4 to 4.4.7.6.6 of the LSA Code and paragraphs 16 and 17 (overhaul examination) of these Guidelines; or
.4 modified and found compliant with paragraphs 4.4.7.6.4 to 4.4.7.6.6 of the LSA Code and paragraphs 16 and 17 (overhaul examination) of these Guidelines; or
.5 replaced by a new lifeboat release and retrieval system.
Lifeboat FPD (Fall Preventer Device) work with shackles to provide the protection for our lives. FPD have been improving and upgrading according to the regulation since 2013.
» MSC.1/Circ.1327
» MSC.1/Circ.1392
» IACS regulation
» MSC.1/Circ.1466
On or after 1stJan 2013, FPD should comply with IACS rules & MSC 1466.
背景
1. 为防止救生艇事故，针对 SOLAS 公约船舶所配备的救生艇的释放及回收系统(以下简称“艇钩系统”)的安全性，在 2011 年 5 月的第 89 次海安会上通过了一套对 SOLAS公约和救生设备规则的修正案以及相关文件。这套修正案及相关文件适用于所有船舶上安装的救生艇（及适用的救助艇）上的艇钩系统（含现有及新建的客船和货船）。
实施要求
2. 于
3．于
4．于
4.1 应根据 MSC.1/Circ.1392“救生艇释放及回收系统评估和更换导则”（见本通函附
件 4）评估每艘这种船舶上配备的现有艇钩系统是否符合经 MSC.320(89)号决议（见本通函附件 2）修正的 LSA 规则
FPD/Fall Preventer Device For Lifeboat Equipment
船舶救生艇防坠落装置
特点：
符合国际海事组织通函MSC.1/CIRC.1327以及国际船级社协会IACS UI SC254的要求
有船级社CCS/LR等船检
采用高分子聚乙烯绳/UHMWPE ROPE/或迪尼玛/DYNEEMA ROPE等高强度索具
独家采用德国进口海工防腐化合物防护
外观采用国际惯用橙色
产品经CCS船级社检验产品破断强度全部大于350kN,大于等于35T
FPD-I
缆绳/CABLE ROPE
产品名称/Name of Product :高分子聚乙烯绳/UHMWPE ROPE
结构形式/Structure :12股/Strand
公称直径/Nominal Diameter :
长度/Length :
标称破断强力/Nominal Breaking Load :356 Kn
名义线密度/Linear Density :547 Ktex
实际破断强力/Actul Breaking Load :356.5 Kn
实测线密度/Actual Linear Density :620 ktex
数量/Quantity :100 条/pcs
断裂部位/Breaking Position :未断/Unbroken
生产日期/Manufacturing Date :2012.09
FPD-II
缆绳/CABLE ROPE
产品名称/Name of Product :迪尼玛绳/Dyneema Ropes
结构形式/Structure :12股/Strand
公称直径/Nominal Diameter :
长度/Length :
标称破断强力/Nominal Breaking Load :350 Kn
名义线密度/Linear Density :212 Ktex
实际破断强力/Actul Breaking Load :362 Kn
实测线密度/Actual Linear Density :219 ktex
数量/Quantity :50 条/pcs
断裂部位/Breaking Position :未断/Unbroken
生产日期/Manufacturing Date :2014.01
FPD-III
缆绳/CABLE ROPE
产品名称/Name of Product :高分子聚乙烯绳/UHMWPE ROPE
结构形式/Structure :12股/Strand
公称直径/Nominal Diameter :
长度/Length :
标称破断强力/Nominal Breaking Load :307 Kn
名义线密度/Linear Density :368 Ktex
实际破断强力/Actul Breaking Load :427.3 Kn
实测线密度/Actual Linear Density :370 ktex
数量/Quantity :100 条/pcs
断裂部位/Breaking Position :头部/End
生产日期/Manufacturing Date , ; :201.07
